Green and Environmental Friendly
Pure electric drive, zero emission, low noise, can reduce carbon emission by 85 tons/year.
High security
Structurally: the battery, battery frame and motor electronic control adopt vibration damping technology with independent intellectual property rights.
Control: three-level safety alarm protection, the whole machine adopts closed high-voltage system, high-voltage interlock, equipotential, insulation detection, multi-point grounding and other multi-level safety design.
Super adaptable
Using battery insulation technology and advanced constant temperature thermal management system, it can adapt to various harsh working conditions such as extreme cold, extreme heat, and high altitude.
Outstanding performance
Adopt H-box integrated design frame battery, match with high-efficiency motor, double-gun fast charge is fully charged in 1.5 hours, and continuous operation is 5~7 hours;
Large compaction depth, the maximum excitation force is 590kN, the maximum compaction thickness exceeds 100 cm, and uniform compactness.
Super Continuation of working time
International first-class brand high energy density lithium iron phosphate battery;
Double-gun fast charge, 1.5 hours full;
Super large power, continuous operation for 5~7 hours;
Large Tonnage
33 tons of super tonnage, super power, high working efficiency, good compaction effect
Energy-saving and efficient
Self-developed and customized high-power motor with excellent performance matching, intelligent control, energy saving and high efficiency
The motor drive has fast response, large torque and no idle speed.
Comfortable and convenient
Comfortable and luxurious large seats, excellent operating vision;
High-definition reversing image to ensure safe operation;
Lower working noise and less vibration than diesel engines, greatly reducing driver fatigue and noise hazards
High Economical Efficiency
Compared with diesel engines, based on 3,000 hour/year, the cost can be saved by USD75,000 in one year and USD375,000 in five years.
